j5create JUD481 Boomerang Station - Universal USB 3.0 Docking Station
j5create JUD481 Boomerang Station - Universal USB 3.0 Docking Station is backordered and will ship as soon as it is back in stock.
Pickup available at DokkanTech
Usually ready in 1 hour
j5create JUD481 Boomerang Station - Universal USB 3.0 Docking Station
Description
Description
The j5create JUD481 Boomerang Station is a Universal USB 3.0 Docking Station
that expands the connectivity of compatible Windows and macOS computers through a single USB connection. Featuring VGA and HDMI display outputs, Gigabit Ethernet, four USB 3.0 ports (including two charging ports), and audio connections, it creates a convenient desktop workspace for productivity, office environments, and home offices
Key Features
- Universal USB 3.0 docking station for supported Windows and macOS computers
- Two display outputs: VGA (DB-15 female) and standard HDMI (female)
- HDMI output carries audio together with video
- Maximum display resolution up to 2048 × 1152
- Video playback up to 1080p
- Four USB 3.0 Type-A ports in total for peripherals and accessories
- Two of the four USB 3.0 ports support Battery Charging v1.2 with up to 2A
- Gigabit Ethernet (RJ-45) for reliable wired network connectivity
- 3.5 mm audio output and 3.5 mm microphone input
- Primary, Extended, and Mirror display modes with 0°, 90°, 180°, and 270° screen rotation
- Driver installation required on Windows and macOS
Key Specifications
| Specification | Details |
| Brand | j5create |
| Model | JUD481 |
| Product Type | Universal USB 3.0 Docking Station |
| Host Interface | USB 3.0 Micro-B (Female) |
| Host Cable Specification | USB 3.0 Micro-B to USB Type-A |
| Display Outputs | 1 × VGA (DB-15 Female), 1 × HDMI (Female) |
| Maximum Display Resolution | Up to 2048 × 1152 |
| Video Playback | Up to 1080p |
| Display Modes | Primary / Extended / Mirror |
| Screen Rotation | 0° / 90° / 180° / 270° |
| USB Ports | 4 × USB 3.0 Type-A (total) |
| Charging Ports | 2 of the 4 USB 3.0 ports support Battery Charging v1.2 (up to 2A) |
| Ethernet | Gigabit Ethernet (RJ-45) |
| Audio | 3.5 mm Audio Out, 3.5 mm Microphone In |
| Power | Self-powered; external power adapter 5V/3A or 5V/4A |
| Driver Required | Driver installation required on Windows and macOS |
| Compatible Operating Systems | Windows, macOS |
| Warranty | Warranty coverage according to the applicable terms and DokkanTech's Warranty Policy. |
Best For
- Office and business workstations.
- Home office productivity.
- Connecting external monitors.
- Wired networking.
- Expanding USB connectivity for laptops and desktops.
Compatibility Notes
The j5create JUD481 is compatible with supported Windows and macOS computers. It connects through a USB 3.0 Micro-B host interface, using a USB 3.0 Micro-B to USB Type-A cable specification. Driver installation is required on both Windows and macOS before video output is available. Display output is provided through the VGA or HDMI connection on compatible monitors. Where additional displays are needed, up to six adapters can be used on Windows and up to four adapters on Mac; these limits refer to using multiple adapters, not to outputs from a single dock. The dock is self-powered and operates with an external power adapter rated 5V/3A or 5V/4A.
Frequently Asked Questions
What warranty applies?
Warranty coverage according to the applicable terms and DokkanTech's Warranty Policy.
What display outputs does it have?
The dock provides one VGA (DB-15 female) output and one standard HDMI (female) output. The HDMI output carries audio together with the video signal
What is the maximum supported resolution?
The maximum display resolution is 2048 × 1152, with video playback up to 1080p
How many USB ports does it have?
It provides four USB 3.0 Type-A ports in total: two standard USB 3.0 ports and two USB 3.0 Battery Charging v1.2 ports supporting up to 2A
Do I need to install software?
Yes. Driver installation is required on Windows and macOS to enable video output
Does it provide a wired network connection?
Yes. It includes a Gigabit Ethernet (RJ-45) port for wired networking
